Maxon Machinery

OZ-Form OZ-20 (Australian made)
5 station, .5-1mm capacity, Pittsburg lock and right angle flange.
1.1kw 240volt, Ex Govt.

OZFORM OZ-20

Colchester Master 2500
335mm swing o/bed (210mm o/slide) x 635mm centres
40mm bore, speeds 30-2500rpm, mm & tpi threading
3 & 4 jaw chucks, fixed and travelling steadies, face plate, 2 axis DRO,
quick change tool post, taper turning, sundry tooling. 5hp motor.
Weight 840kg, Manuals, Ex Govt

COLCHESTER MASTER 2500

HAFCO Metal Master BM-70VE milling machine
40iso spindle, speeds 70-4200rpm electric variable (2 ranges),
table 1500mm x 305mm, travels X-1050mm, Y-420mm, Z-400mm
electric variable feed X/Y, rapid positioning for Z.
5hp 415 volt. 3 axis DRO, power draw bar, vice, and sundry tooling.
Machine weight 1800kg, manual.

HAFCO METALMASTER BM-70VE

Scledum RG200N Crank Shaft Grinder
with steady rests, various indicator gauges, wheel dressers,
magnetic separator coolant system.

SCLEDUM RG200N

Brobo Waldown NF-350 cold saw on stand
350mm dia blade, 1 speed 415 volt
Capacity:
Round 118mm dia at 90 degrees, 110mm at 45 degrees
Square 105mm at 90 degrees, 90mm at 45 degrees
Comes with spare blades.

BROBO WALDOWN NF-350

Jones & Shipman 1300 universal cylindrical grinder
254mm max dia x 686mm centres, table traverse 76-3658mm/min,
table swivel 16 degrees, work head variable speed, coolant system.
machine weight 1950kg

JONES & SHIPMAN 1300

John Heine 205A Series 2 incline press
40ton, 3.25" stroke, 2.5" adjustment of slide.
110 strokes per min max, 5hp 415 volt motor.
Vee Bar bed guards, machine weight 2900kg

JOHN HEINE 205A SERIES 2

Servex HP100 work shop press
High/Low pressure (fast/slow)
1143mm between  uprights, 203mm between table channels,
178mm ram travel, 190mm screw travel, 178mm dia cylinder.
Comes with V blocks, flat chuck, Vee chuck, extension handle.
Floor space 1575mm x 1279mm. 914kg.
The last new HP100 press available.

SERVEX HP100

AMC L-2500 line borer.
Maxon block length 2500mm, speeds 50-750rpm (6 off),
includes 60mm, 40mm & 25mm boring bars with bearings and centering rings, cutter heads, various measuring and setting gauges.
Sundry accessories and original manual.
Machine weight 2700kg

AMC L2500

A.P.Lever model 4Y Wheeling Machine/English Wheel. Quality cast iron Australian machine. Comes with new set of 30mm nylon anvils and urethane band. Ex Govt.

AP LEVER 4Y WHEELING MACHINE

OTHER -

Berco BT6 line borer
Boring range 24-85mmm max spindle travel 100mm,
Min- Max distance from parallel supports to boring bar 45-295mm
Max length block or head admitted 810mm
Max width cylinder head 300mm
Speeds 215, 355, 445, 520, 730, 1070rpm.
415 volt .37kw spindle motor.
Various boring bars, gauges, mounts etc
Machine weight 370kg

BERCO BT6
