Maxon Machinery

Berco BT6 line borer
Boring range 24-85mmm max spindle travel 100mm,
Min- Max distance from parallel supports to boring bar 45-295mm
Max length block or head admitted 810mm
Max width cylinder head 300mm
Speeds 215, 355, 445, 520, 730, 1070rpm.
415 volt .37kw spindle motor.
Various boring bars, gauges, mounts etc
Machine weight 370kg

BERCO BT6

LA-430 x 1100
432 mm swing o/bed (272 mm o/slide, 610 mm in gap) x 760 mm centres. 58 mm spindle bore, 35-2000 rpm, mm and tpi threading, 3 and 4 jaw chucks. Fixed and travel steadies.  5hp motor machine weight 1600kg. ex govt.

EXIMUS LA430 X1100

Arboga U1E-RLM 4mt, 1000mm arm, speeds 90-1500rpm, feeds .1-.33mm/r, 195mm quill travel, 670mm vertical arm movement, auto reverse/taping,
400mm x 500mm box table, 415volt, machine weight 1200kg, machine manual.
Ex Govt, as new.

ARBOGA U1E-RLM

Samco Mini Max Formula SP1
520mm wide x 250mm max height, table 520mm x 1000mm,
power table elevation, feeds 5, 8, 12, 18 m/min.
cutter head speed 4500rpm. 415 volt 7.5hp main motor
Includes blade setting jig. DOM 2000
Machine weight 663kg

2000 SCM MINIMAX FORMULA SP1

Richards of Leicester type RMB-5, 1200 mm dia, 5.5 kW motor, lump breaker, loading car, vibrating screen - feed conveyor unit.

RICHARDS OF LEICESTER RMB-5

Jones & Shipman 540 surface grinder
450mm x 150mm table, fitted with 500mm x 200m magnetic chuck.
max travels 480mm long, 170mm cross, 280mm vertical. takes 178mm dia wheel. 2hp spindle motor. 415 volt.  Coolant system. Ex Govt.
Machine weight approx 780kg.

JONES & SHIPMAN 540

WEINGARTEN Forging Press Mod PS160, max pressure 250 tons, stroke 120mm - 360mm

1974 WEINGARTEN FORGE PRESS PS160

Archer 60ton workshop press, 2 speed (high &amp; low pressure) max stroke on ram 180mm. 200mm wide between table, 1150mm between uprights, wind up table. New V blocks, comes with press brake attachment (multi V block and 2 x blade blocks)
Ex Govt.

ARCHER 60 TON

Pacific FCM-1400 ram head milling machine.
50 int spindles, 400mm x 1400mm swivel table, travels X-950mm, Y-330mm, Z-465mm, Overarm - 550mm.
Feeds and rapids to X, Y, Z & overarm. Spindle speeds 28-1400rpm horizontal and vertical.
Motors 6hp horizontal and 7.5hp vertical. Vice and operators manual.
Ex Govt, machine weight 3500kg.

PACIFIC FCM-1400

Heska (German) ESA-5, 500mm throat, 230mm height.
2 axis tilting 600mm square table. Variable speed 2 ranges.
On board blade welder and grinder. 415volt.
Manual. Weight approx. 760kg

HESKA ESA-5

Euro-Source 2-VS
R8 spindle, 230mm x 1240mm table, approx travels X-900mm, Y-360mm, Z-355mm.
Speeds 75-3800rpm variable. Power feed to X and Z axis.
3 axis Newall DRO, 3hp 415volt. Work light, vice.
Machine weight approx 1100kg

EURO-SOURCE 2VS

Startrite 20V bandsaw
510mm throat, 250mm height of cut. speeds 15-910 m/min (10 off)
520mm x 520mm tilting table, blade welder and grinder.
1.5kw 415v motor. Ex Govt.

STARTRITE 20V
