Maxon Machinery

Pullmax P-5 Nibbler
Up up to 6mm capacity max* in m/s 1050mm throat, 19mm tooling.
Tooling for Beading, Cutting, Joggling, Flanging, Doming, Slot Cutting
With circle cutting centres, straight cutting fence. 415 volt.

PULLMAX P5

Pullmax P2 Nibbler
880mm throat, 16mm tooling.
Very well tooled: includes tooling for Doming, Edge Bending,
Louvring, Flanging, Joggling and Cutting.
Guide for straight cutting, Circle cutting centres. Ex Govt. 415 volt.
Weight aprpox 400kg

PULLMAX P2

Servex HP60-MK2-P3 Workshop Press
600kN (60t) Rolling head
Between up rights - 991mm
Between table channels -203mm
Table height adjustment - 813mm
Screw travel - 178mm
Ram travel - 178mm
Weight - approx 650kg
New cylinder kit, vee blocks and flat chuck.
3hp, 415volt. Ex Govt.

SERVEX HP60-MK2-P3

Servex HP100-P3 Workshop Press
100 ton
Between up rights - 1143mm
Between table channels -244mm
Table height adjustment - 762mm
Screw travel - 150mm
Ram travel - 178mm
Weight - approx 1000kg
3hp, 415volt.

SERVEX HP100-P3

Pacific-Lagun FCM-2000 ram head milling machine 450mm x 2000mm table, 50ISO spindles, speeds 56-1400rpm ram head, 28-1400rpm horizontal, travels X-1300mm, Y-430mm, Z-480mm, Ram-640mm, feeds and rapids, comes with various tooling, collet chuck, vice, dividing head.
Motors Horizontal 15kW, overarm 7.3kW, 415 volt.
Machine weight approx 4500kg

PACIFIC FCM-2000

Colchester Master VS-3250 lathe
350mm swing o/bed (195mm o/slide, 535mm in gap) x 650mm centres,
gap bed. 42mm spindle bore, speeds 0-3250rpm variable (3 ranges) mm and tpi threading, 3 and 4 jaw chucks, fixed and traveling steadies, 2 axis DRO, quick change tool post. with 6 holders, 7.5kw 415 volt
Manual, machine weight 1350kg. Ex Govt

1995 COLCHESTER MASTER VS 3250

Colchester Mastiff 1400
535mm swing o/bed (370mm o/slide, 815mm in gap) x 2000mm centres, 18-1400rpm, mm & tpi threading, 90mm bore. 6mm pitch screw.
Colchester Pratt Burnard 3 and 4 jaw chucks, face plate, 1 x fixed steady, 1 x travel steady, quick-change tool post with 6 holders.
2 Axis DRO, 12.5hp motor, machine manual, sundry tooling.
Weight approx 2650kg.

COLCHESTER MASTIFF 1400

JAFO Jaracin FWD-32U universal milling machine.
40 ISO spindles, speeds 56-1800rpm, 313mm x 1230mm swivel table, feeds and rapids. Travels X-650mm, Y-250mm, Z-426mm.
Vertical head, dividing head, vice, sundries in tool cabinet.
Motor 4.5kw 415 volt, ex Govt.
Machine weight approx 2120kg.

JAFO JAROCIN FWD-25

Harrison 11" centre lathe
285mm swing o/bed (180mm o/slide, 500mm in gap) x 600mm centres
speeds 34-1500rpm, spindle bore 34mm, 3 and 4 jaw chucks,
face and dog plates, fixed and travel steadies, coolant.
3/4.4hp 415volt motor. Ex Govt.

HARRISON 11"

Servex HP100-MK2-P3 Workshop Press
1000kN (100t) Rolling head
Between up rights - 1143mm
Between table channels -244mm
Table height adjustment - 762mm
Screw travel - 190mm
Ram travel - 178mm
Weight - approx 1000kg
Fitted with interlocked safety guards to table and depth limit.
New cylinder seals, vee blocks, flat chuck gauge and hoses.
Lates series press, Ex Govt training.

2015 SERVEX HP100-MK2-P3

Colchester Master VS-3250 lathe
350mm swing o/bed (195mm o/slide) x 650mm centres
42mm spindle bore, speeds 0-3250rpm variable (3 ranges)
mm and tpi threading, 3 and 4 jaw chucks. 7.5kw 415 volt
Manual, machine weight 1350kg. Ex Govt

COLCHESTER MASTER VS 3250

Servex HP30 Workshop Press
30ton
Between up rights 711mm
Between table channels -152mm
Table height adjustment 889mm
Screw travel 170mm
Ram travel 152mm
Weight 280kg
New cylinder and pump kits, vee blocks, extension handle, table pins and flat chuck.
Ex Govt.

SERVEX HP-30
