Maxon Machinery

Hwacheon HL-460 x 1000GN gap bed lathe
460mm swing o/bed (280mm o/slide, 680mm in gap) x 1000mm centres
52mm spindle bore, speeds 32-1800rpm, mm and tpi threading,
2 speed tail stock, DRO, 3 and 4 jaw chucks, face plate.
5.5kw 415volt, approx 2000kg Quality Korean Machine

HWACHEON HL460 X 1000GN

HAFCO Metal Master CL-75
560mm swing o/bed (350mm o/slide, 788mm in gap) x 2000mm centres
80mm spindle bore, 25-1600rpm, mm and tpi threading, 10hp 415 volt motor, 3 & 4 Jaw chucks, fixed steady, 2 axis DRO, manuals.
Machine weight approx 2750kg

HAFCO METALMASTER CL-75

ZB3060x16
5mt, speeds 38-2000 variable 2 ranges, feeds .06-1.0 mm/rev
Spindle to collum 400mm min 1620mm max, 350mm quill travel,
hydraulic independent locking, 4kw main motor 415volt.
box able 500mm x 710mm x 400mm. machine weight approx 3800kg

2012 ZJ ZB3060 X 16

Phillips Imperial Lathe
550mm swing o/bed (375mm o/slide, 740mm in gap) x 1600mm centres. 50mm spindle bore, 25-1500rpm, mm and tpi threading, 3 and 4 jaw chucks, fixed and travel steadies, quick change tool holder.

PHILLIPS-IMPERIAL 550 X 1600

Quantum FM-4V Turret Mill
40iso spindle, speeds 50-3335rpm variable (2 ranges)
Table 254mm x 1370mm power feed to X axis.
Travels X-800mm, Y-380mm Z-400mm. 3.7kw/5hp 415 volt motor
3 axis DRO, coolant, work light, vice, sundry tooling.
Machine weight approx 1300kg

MFI-QUANTUM FM-4V

A&S Conveyors tacker conveyor
750mm wide chevron belt x 13m,
7.5kw motor gear box speed 71rpm

A&S CONVEYORS 750MM X 13M

ZMM Mashtroy model C11MSM103,
600 mm swing O/bed (390 mm carriage, 790 mm in gap) x 3000 mm centres, 103 mm spindle bore, 8-1400 rpm, mm and tpi threading.
Rapid traverse, 2 axis DRO, 300 mm 3 Jaw & 500 mm 4 Jaw chuck, fixed steady. DOM2007. Manual and some tooling.

2007 ZMM BULGARIA C11MSM103

Dynamic Twin Roll crusher
400mm x 400mm, twin 5.5kw 720rpm motors.
V belts and belt guards. DOM 2021
unit weight 2500kg. Unused condition.

DYNAMIC 400MM X 400MM

Colchester Master VS-3250 lathe
350mm swing o/bed (195mm o/slide) x 650mm centres
42mm spindle bore, speeds 0-3250rpm variable (3 ranges)
mm and tpi threading, 3 and 4 jaw chucks. 7.5kw 415 volt
Manual, machine weight 1350kg. Ex Govt

COLCHESTER MASTER VS 3250

Dashin Champion 1550 centre lathe
390mm swing o/bed (240mm o/slide, 610mm in gap) x 1250mm centres
55mm spindle bore, 25-2000rpm, mm and tpi threading.
New chucks, sundry tooling. 5.5kw motor 415 volt
Machine weight 1500kg. Ex Govt.

DASHIN CHAMPION 1550

YSD HGN-25/8
Capacity 8mm x 2500mm, (4mm in stainless steel)
variable rake angle 0.5-2.5 degrees,
power back gauge 750mm range, throat 100mm,
17 strokes/min, 11kw motor, DOM 2010.
Machine weight 6000kg, Ex Govt.

2010 YSD HGN 25/8

DoAll 17 centre lathe
430mm swing over bed (242mm o/slide) x 1525mm centres
spindle bore 75mm, speeds 40-2120rpm (18)
mm and tpi threading, 2 x 3 jaw & 1 x 4 jaw chucks
2 x fixed steadies, quick change tool holder
10hp 415 volt motor, machine weight approx 2200kg

DOALL 17
